Project

 Datas

4CH

8CH

System

Language

Chinese/English

Operation system

Linux

Operation interface

Graphical menu operation interface（OSD menu），Character overlay function；

GUI

Support mouse、remote configuration

Processor and CPU

CPU

ARM Cortex CA9 Dual core@1.4GHz

Memory

1GB DDR3

Videoand record system

Video input

4 CH CVBS，1.0Vp-p, 75Ω

8 CH CVBS，1.0Vp-p, 75Ω

Support camera resolution：1080P、720P、D1

Video output

1CH VGA，1CH CVBS, 1.0Vp-p, 75Ω, Support Full Screen and 4/9 CH Division

Video standard

PAL 、NTSC

Video compress format

H.264/H.265

Preview

Singular 、4/9 image mosaic preview，support hand operation/emergency case trigger full screen

Video resolution

1080P、720P、D1、HD1、 CIF Optional, Coding:1080P 150 frames

Video quality

1~8 level, Top ：1 level, bottom：8level

Video rate

PAL: 100f/s , CCIR625 line,50场

NTSC: 120f/s, CCIR525 line,60场;

CIF: 256Kbps ~ 1.5Mbps, ( Multi-level video quality optional)

HD1: 600Kbps ~ 2.5Mbps, ( Multi-level video quality optional)

D1: 800Kbps ~ 3Mbps, ( Multi-level video quality optional)

720P: 1Mbps-4Mbps, ( Multi-level video quality optional)

1080P: 1Mbps~8Mbps, ( Multi-level video quality optional)

recording methods

Default automatic record，support ignition record、alarm record etc.

Audio

input

4CH analog audio

8CH analog audio

output

1CH，Optional：built-in and external

Compression

G.711A

Audio methods

Audio and video are recorded simultaneously

Alarm input

6CH Switch on/off

Alarm output

1CH，Linkage sound and light alarm、oil cut-off and power-off etc.

Communication interface

1 USB

1CH RS232 ，Expandable card reader, oil sensor

1CH RS485，Expandable PTZ

1 CH 10M/100M Adaptive network interface，Support TCP/IP，FTP，DDNS network protocol.

Expand interface

1CH intercom interface，intercom handle available

Multifunctional control panel（support 12V and RS232）

Wireless transmission

Built in 4G wireless transmission , TDD-LTE, FDD-LTE

WIFI:wireless 802.11b/g/n communication mode

GPS

Builtin GPS / BD mode

Sensor

builtin 3 axes acceleration sensor and 3 axes Axial gyroscope sensor

Disk

Disk

Builtin sata interface disk，Max 4T

SD card

1 SD card，Max 512G, support synchronous sub-code recording

upgrade

Support U Disk upgrade，SD card upgrade、FTP Remote automatic upgrade

storage

Raw storage

USB

Front USB ，U Disk upgrade backup data；support USB mouse

SIM interface

1 SIM interface

Video playback

Video search

Search via date, methods

playback

Support 4CH synchronous playback，support 2, 4, 8, 16X fast forward or rewind.

Support 8CH synchronous playback，support 2, 4, 8, 16X fast forward or rewind.

AI algorithm

ADAS

off lane、passerby、vehicle distance Detection

DSM

DSM driver state analysis system provides the response of capturing driver

physiological image with optical lens. Based on the driver's facial features, eye signals, head movement, etc., DSM driver state analysis system can infer the driver's fatigue

state, abnormal behavior and camera state, and give voice alarm and prompt

BSD

Blind spot monitoring

Power consumption

Power management

Multi-power-range-input,overload,under-volt,short-circuit,reverse connection ,protection;support timing switch, delay shutdown function

Input volt

DC:+9V ~ +36V

Output volt

+12V@1A，+5V@1A

Power consumption

Normal and regular working ＜8W（no external device）

Working situation

temperature

-10℃ to +70℃

humidity

20% to 80%

Safety management

Password access

User 、administrator

Platform

JT/T808-2011, JT/T808-2019

JT/T1076-2016, JT/T1078-2016

TTX private protocol、GB28181、RTMP (optional)

Dimension

195mm*183mm*60mm

Net weight

1.6kg
