OX-A2 (4G HD surveillance ball)

  • Brand   YQYWR
  • Model   OX-A2
  • Description

    4G HD surveillance ball,4G 3G Wifi Bluetooth GPRS GPS Police DVR Police DVR,Body Camera,Police Camer...


4G 3G Wifi Bluetooth GPRS GPS  HD surveillance ball

Intercom, Support multi person meeting

Opreting system  Android 7.1.1
Chipset  MTK6739
Processor  Quad-core ARM@Cortex-A53 MPCore 1.3GHz/512KB unified L2 cache
Sensor   1/2.7 SONY COMS SENSOR
Storage capacity Support 16G/32G/64G/128(With Standard 32GB TF Card)
4G/3G function  4GB1/B3/B5/B8/B34/B38/B39/B40/B41 3G: B1/B5/B8/BC0(CDMA2000)
Wifi function builtin,support 802.11b/g protocol/2.4GHZ
GPS function Built in Beidou global positioning module (support for mobile trajectory query)
bluetooth function BT4.0
Screen  0.95 inch Touch screen  16:9
Video coding resolution 1920X1080 30P  MP4 format
Video Bitrate 256kbps-8Mbps
Lighting device Built-in  Infrared lamp, automatic IR function
Lens focal length  F=4.8mm~94mm
Optical multiple / aperture value 20 times / F1.6~F3.5
Digital zoom / focus 40 times / automatic synchronization
Luminance  1000cd/ square meters
Battery  Built-in 20000mah li battery
Charging time/service life 12.0hours/ continuous use for more than 20000 hours
Minimum illumination Color: 0.05Lux@F1.6, black/white :0.01Lux@F1.6, IR on: 0Lux
Gain control automatic / manual, the signal-to-noise ratio52dB
Electronic shutter  1/ 1 second to 1/10000 seconds
Horizontal perspective  61.4-2.9 degree (wide angle - telescopic)
Minimum working distance 10mm-1500mm (wide angle - telescopic)
Horizontal range 360 degrees of continuous rotation, the horizontal velocity of 0.05 to 100 degrees /s
Operating temperature  -30 degrees C to +80 degrees C
Management software  1.Real time playback: support real-time 16 way data
2.Data upload: support D1 720P 1080P H.264 data upload
3.Beidou Positioning trajectory: support to view moving trajectory
4.Wireless intercom:Real time 4G network wireless intercom,Multi person meeting



Completely portable color video and audio recorder is the must have camera for event recording. Keep a record of your interactions with suspects or criminals. No more worry about whether or not someone has told a different story or behaved poorly only to blame yo u. This miniature video cam with audio is the prefect device to cover your actions in the field or document a scene. Perfect for anyone who needs to capture video and audio on the go.
